HPE Networking Comware Switch 24SFP+ 6QSFP+ or 2QSFP28 5710
- Brand: HPE
- Category:
- SKU: JL587A
- EAN: 0190017284682 0190017284699
Offer details
Reasons To Buy
Accelerate Application Performance
The HPE Networking Comware Switch Series 5710 are high density, low-latency switches, the perfect solution for bandwidth-intensive workloads.
Two-tier network design delivers outstanding performance while protecting and extending existing Hewlett Packard Enterprise or 3rd party core network investments.
Delivers up to 1,440 Gbps switching capacity for the most demanding applications.
Low latency, under 1.5 µs 10GbE latency, provides improved throughput and fewer lost packets.
Simplify Administration and Support
The HPE Networking Comware Switch Series 5710 addresses small to mid-size organizations needing fixed high-performance and low-latency 1/10GbE top-of-rack data center switches for server connectivity
The HPE Networking Comware Switch Series 5710 includes the HPE Intelligent Resilient Framework which reduces administrative touchpoints by making multiple physical switches appear as a single virtual switch from a management perspective.
Reduce Cost and Simplify Operations While Accelerating Performance
HPE Networking Comware Switch Series 5710 reduces lock-in and having to replace the hardware. Unlike competitive products based on proprietary technology and closed designs, the 5710 Series switch top-of-rack products are based on industry standards and an open architecture.
Removes hidden software expenses; the all-inclusive HPE Comware Switch license includes a complete set of advanced features.
High-performance IP-attached switching allows the reduction of equipment and operations expense and complexity and delivers fast connectivity for HPE 3PAR, HPE Nimble, HPE SimpliVity or third-party storage arrays.
Hewlett Packard Enterprise Servers and Networking are Better Together
HPE Networking Comware Switch Series 5710 helps accelerate performance, simplify operations and contain costs.
HPE ProLiant Servers, server networking options, HPE Comware top-of-rack switches, transceivers and cables are designed and tested to work better, together.
Ability to migrate your compute, storage and networking infrastructure to support the most business critical applications - with confidence.
Description
What is new supporting point:
New made in USA TAA-compliant SKUs offer heightened security via manual and automated source code analysis to address common programming issues, easing concerns about "made in China" products
Provides choices that fit your budget and IT environment by offering different port density and speeds (1/10G) SFP+ or 10BASE-T with 40 and 100GbE high speed uplinks options.
Affordably priced, with full support for Layer 2, Layer 3, IPv4 and IPv6 networking protocols at no additional cost for these advanced features.
Delivers up to 1,440 Gbps switching capacity for the most demanding applications.
Low latency, under 1.5 µs 10GbE latency, provides improved throughput and fewer lost packets.
Specifications
Management features | |
---|---|
Switch layer | L3 |
Switch type | Managed |
Quality of Service (QoS) support | Yes |
Ports & interfaces | |
SFP+ module slots quantity | 24 |
Basic switching RJ-45 Ethernet ports quantity | 0 |
Basic switching RJ-45 Ethernet ports type | No |
Network | |
Networking standards | IEEE 802.1D, IEEE 802.1Qau, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1ab, IEEE 802.1ag, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ah |
Spanning tree protocol | Yes |
Link aggregation | Yes |
Flow control support | Yes |
10G support | Yes |
IPv6 FIB entries | 8000 |
IPv4 FIB entries | 16000 |
Data transmission | |
MAC address table | 208000 entries |
Switching capacity | 960 Gbit/s |
Throughput | 714 Mpps |
Latency (10 Gbps) | 1.5 µs |
Jumbo frames support | Yes |
Packet buffer memory | 12 MB |
Security | |
Access Control List (ACL) | Yes |
Authentication type | IEEE 802.1x, RADIUS |
DHCP features | DHCP client, DHCP server |
Protocols | |
Routing protocols | BGP, IP, MPLS, OSPF, RIP, VRRP |
IPv6 FIB entries | 8000 |
IPv4 FIB entries | 16000 |
Design | |
Rack mounting | Yes |
Stackable | Yes |
Product colour | Black |
Form factor | 1U |
Performance | |
Virtual stacking (units) | 10 |
Memory type | SDRAM |
Internal memory | 4096 MB |
Flash memory | 1024 MB |
Stackable | Yes |
Packet buffer memory | 12 MB |
Harmonized System (HS) code | 85176990 |
Power | |
Power supply included | Yes |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Redundant power supply (RPS) support | Yes |
Power over Ethernet (PoE) | |
Power over Ethernet (PoE) | No |
Operational conditions | |
Operating temperature (T-T) | 0 - 45 °C |
Operating relative humidity (H-H) | 10 - 90% |
Heat dissipation | 457 BTU/h |
Weight & dimensions | |
Width | 440 mm |
Depth | 400 mm |
Height | 44 mm |
Weight | 8.55 kg |
IPv4 & IPv6 features | |
IPv6 FIB entries | 8000 |
IPv4 FIB entries | 16000 |
Technical details | |
Harmonized System (HS) code | 85176990 |
Logistics data | |
Harmonized System (HS) code | 85176990 |
