StarTech.com 8 Port 1U Rackmount DVI USB KVM Switch

StarTech.com 8 Port 1U Rackmount DVI USB KVM Switch

  • Brand: StarTech.com
  • Category:
  • SKU: SV831DVIU
  • EAN: 0065030842303 0172302708806 01 ...2708806 0163120911066 0132017927749 0806291857053 0617407485622 0168141487422more
StarTech.com 8 Port 1U Rackmount DVI USB KVM Switch - USB DVI KVM Switch - DVI KVM Switch - USB KVM Switch

Trade Prices

Distributor Product SKU Stock Updated Price
AU - Dicker Data Limited 8 Port 1U Rackmount DVI USB KVM Switch - 8 Port KVM Switch 3YR SV831DVIU Register free see stock
AU - Ingram Micro 8 Port 1U Rackmount DVI USB KVM Switch - USB DVI KVM Switch - DVI KVM Switch - USB KVM Switch 1861421
NZ - Dicker Data .com 8 Port 1U Rackmount DVI USB KVM Switch - 8 Port KVM Switch 3 YR SV831DVIU
NZ - Ingram Micro 8 Port 1U Rackmount DVI USB KVM Switch 1861421

Related Products

Description

The SV831DVIU 8-Port 1U Rack Mount DVI USB KVM Switch lets you control up to 8 USB-connected computers (each with DVI or HDMI display output) from a single keyboard, mouse and monitor.

The KVM switch offers maximum control, allowing you to switch computers using hot-key commands or front panel push-buttons. Supporting digital resolutions up to 1920x1200 via DVI or HDMI connection (using DVI to HDMI adapter - see accessories), the KVM provides the high resolutions recommended for newer displays, allowing you to take full advantage of your monitor/screen capability.

A perfect addition to any server room or software test lab, this rugged 8-port switch can be rack-mounted into 1U of cabinet space.

Backed by a StarTech.com 3-year warranty and free lifetime technical support.

Note: This KVM supports digital signals only, and cannot be used with DVI-to-VGA adapters.

The StarTech.com Advantage
- High-resolution 1920x1200 DVI connections support control of DVI systems or HDMI systems (with adapter)
- Supports wireless and combo style mouse and keyboard sets for added flexibility
- Rugged, solid steel rack-mountable case offers durability even in harsh environments

Specifications

Ports & interfaces
Number of computers controlled8
Keyboard port typeUSB
Mouse port typeUSB
Video port typeDVI-I
Audio connectionsNo
USB 2.0 ports quantity10
Network
Ethernet LANNo
Performance
Daisy chainNo
Maximum resolution1920 x 1200 pixels
Maximum analog resolution1920 x 1200 pixels
Design
Mean time between failures (MTBF)45254 h
Product colourBlack
Rack mountingYes
LED indicatorsYes
Hot keysYes
CertificationCE, FCC
Rack capacity1U
Housing materialSteel
Power
Input current1.8 A
Output current4 A
Power plug typeType M
Compatible power plug typesAU, EU, UK, US
Output voltage12 V
External power adapterYes
Input voltage100-240 V
Video
Maximum resolution1920 x 1200 pixels
Maximum analog resolution1920 x 1200 pixels
Sustainability
Compliance certificatesRoHS
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%
Weight & dimensions
Width438 mm
Depth180 mm
Height44 mm
Weight3.5 kg
Package width265 mm
Package depth595 mm
Package height90 mm
Package weight3.77 kg
Packaging data
Package width265 mm
Package depth595 mm
Package height90 mm
Package weight3.77 kg
Packaging content
Rack mount kitYes
ManualYes
Certificates
CertificationCE, FCC
Other features
IP controlYes
Hot keysYes
Technical details
Compliance certificatesRoHS
Logistics data
Harmonized System (HS) code85176200
