Thermaltake Litepower 500W Gen3 80+ (OEM) power supply unit 20+4 pin ATX ATX Black
- Brand: Thermaltake
- Category:
- SKU: PS-TTP-0500NNSAWA-1
- EAN:
Litepower 500W Gen3 80+ (OEM Version), Active PFC, 200 - 240V
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
THM PSU 500W-LITEPOWER-G3-80-PLUS-BLACK |
II362116 |
Description
Ideal for basic desktop systems with lower power level consumption - where efficiency, reliability and low noise is of utmost importance. Comes in an OEM Pack.
Specifications
| Cooling | |
|---|---|
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
| Cooling type | Active |
| Performance | |
| On/off switch | Yes |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | 80 PLUS |
| Purpose | PC |
| Mean time between failures (MTBF) | 100000 h |
| Design | |
| 80 PLUS certification | 80 PLUS |
| Product colour | Black |
| Fan diameter | 12 cm |
| On/off switch | Yes |
| Number of fans | 1 fan(s) |
| Cooling type | Active |
| Power | |
| Total power | 500 W |
| AC input voltage | 220 - 240 V |
| AC input frequency | 50 Hz |
| Input current | 8 A |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 499.2 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 12.5 W |
| Max output current (+3.3V) | 18 A |
| Max output current (+12V) | 41.6 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2.5 A |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Hold time | 17 ms |
| Ports & interfaces | |
| Motherboard power cable length | 60 cm |
| SATA power cable length | 150,500 mm |
| Peripheral (Molex) power cable length | 150,500 mm |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 4 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| PCI Express power connectors (6+2 pin) | 2 |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 40 °C |
| Storage temperature (T-T) | -40 - 55 °C |
| Operating relative humidity (H-H) | 20 - 85% |
| Storage relative humidity (H-H) | 10 - 95% |
| Certificates | |
| Compliance certificates | CB, Federal Communications Commission (FCC), ICES, cTUVus |
| 80 PLUS certification | 80 PLUS |
| Weight & dimensions | |
| Width | 150 mm |
| Depth | 140 mm |
| Height | 86 mm |
| Technical details | |
| Compliance certificates | CB, Federal Communications Commission (FCC), ICES, cTUVus |
