Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
UniFi USW-Aggregation, 8-port 10G SFP+ Aggregation Switch, Layer 2 Switch, Fanless, 1U Rackmount, |
NHU-USW-AGGREGATION | |||
|
USW-Aggregation |
USW-Aggregation | |||
|
UniFi Switch Aggregation with 10G SFP+ Ports |
USW-Aggregation | |||
|
8PORT 10 GIGABIT SFP+ AGGREGATION SWITCH |
5086045 |
Retail Prices
| Merchant | Product | Condition | Updated | Price |
|---|---|---|---|---|
| Amazon | New | $539.00 | ||
| Amazon | New | $539.00 |
Description
Managed layer 2 aggregation switch sporting (8) 10G SFP+ ports for high capacity link aggregation.
The UniFi Aggregation Switch is a managed Layer 2 switch with eight 10G SFP+ ports. Featuring a compact 4.7" depth and fanless design, it supports high-bandwidth links to provide link aggregation for higher capacity and increased availability.
The UniFi Aggregation Switch is a managed Layer 2 switch with eight 10G SFP+ ports. Featuring a compact 4.7" depth and fanless design, it supports high-bandwidth links to provide link aggregation for higher capacity and increased availability.
Specifications
| Management features | |
|---|---|
| Switch layer | L2 |
| Switch type | Managed |
| Ports & interfaces | |
| SFP+ module slots quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | No |
| Network | |
| 10G support | Yes |
| Data transmission | |
| Switching capacity | 160 Gbit/s |
| Forwarding rate | 119.04 Mpps |
| Throughput | 80 Gbit/s |
| Design | |
| Rack mounting | Yes |
| Product colour | Silver |
| Form factor | 1U |
| LED indicators | System |
| Housing material | Galvanized steel |
| Certification | CE, FCC, IC |
| Performance | |
| Harmonized System (HS) code | 85176990 |
| Fanless | Yes |
| Technical details | |
| Harmonized System (HS) code | 85176990 |
| Power | |
| Power consumption (max) | 30 W |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 442.4 mm |
| Depth | 120 mm |
| Height | 43.7 mm |
| Weight | 2.65 kg |
| Packaging data | |
| Rack mount kit | Yes |
| Cables included | AC |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Packaging content | |
| Rack mount kit | Yes |
| Cables included | AC |
