AEG Protect D. 10000 uninterruptible power supply (UPS) 10 kVA 9000 W 4 AC outlet(s)
- Brand: AEG
- Category:
- SKU: 6000008440
- EAN: 4026245084403
10000VA, 9000W, RS232, Terminal, 3 x C19, USB, EPO, SNMP, LCD
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
AEG Protect D. 10000 (Rack) 10000VA / 9000W |
6000008440 |
Description
Highly efficient with a compact design, Protect D. achieves more than 30% higher power in comparison to conventional UPS systems. Providing outstanding performance, superior reliability and longer autonomy times, Protect D. also offers multiple communication options, advanced battery management and graphical control in one modular unit.
Specifications
| Power | |
|---|---|
| Output power capacity | 10 kVA |
| Output power | 9000 W |
| Input operation voltage (min) | 176 V |
| Input operation voltage (max) | 276 V |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Maximum current | 47 A |
| Efficiency | 97% |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 2% |
| Crest factor | 3:1 |
| Input frequency | 50/60 Hz |
| Performance | |
| Waveform | Sine |
| Power protection features | Overload, Short circuit |
| Noise level | 55 dB |
| LED indicators | Yes |
| Audible alarm(s) | Yes |
| Features | |
| Output power capacity | 10 kVA |
| Output power | 9000 W |
| Input operation voltage (min) | 176 V |
| Input operation voltage (max) | 276 V |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Maximum current | 47 A |
| Efficiency | 97% |
| Emergency Power Off (EPO) | Yes |
| Waveform | Sine |
| Power protection features | Overload, Short circuit |
| Output voltage Total Harmonic Distortion (THD) | 2% |
| Crest factor | 3:1 |
| Noise level | 55 dB |
| Audible alarm(s) | Yes |
| Input frequency | 50/60 Hz |
| Ports & interfaces | |
| AC outlets quantity | 4 AC outlet(s) |
| AC outlet types | C19 coupler, Terminal |
| Power plug | Terminal |
| USB 2.0 ports quantity | 1 |
| RS-232 ports | 1 |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 3 h |
| Hot-swap battery | Yes |
| Battery voltage | 240 V |
| Automatic battery test | Yes |
| Design | |
| Rack capacity | 5U |
| Form factor | Rackmount |
| Product colour | Grey |
| Certification | EN62010-2 EN62040-1 |
| LED indicators | Yes |
| Housing material | Metal |
| Display type | LCD |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 1000 m |
| Weight & dimensions | |
| Width | 486 mm |
| Depth | 715 mm |
| Height | 220 mm |
| Weight | 82.5 kg |
| Certificates | |
| Certification | EN62010-2 EN62040-1 |
