Reasons To Buy
Grow – Expand your capabilities and opportunities
Reproduce everything from technical documents to graphics – even damaged originals – with CCD scanning technology.
Create large-format colour and monochrome scans/copies up to 1067 mm (42 inches) wide, even on thick[1] media.
Produce incredibly accurate and high-quality scans with 1200 dpi optical resolution.
Easily share and collaborate – scan to HP SmartStream software,[2] email, USB, network folders, and HDDs.
Accelerate – Speed up production and drive results
Accomplish more with incredible speeds – scan 33 cm (13 inches/sec) in either colour or monochrome.[3]
Experience an uninterrupted workflow with advanced touchscreen controller that enables ultra-fast processing.
Save time operating and managing your scanner with an intuitive user interface that requires less clicks to final scan.
Be more productive with improved compression options, unlimited presets, multi-page PDFs, and collating.
Optimise – Integrate and secure your workflow
Enjoy seamless integration with HP PageWide XL and HP DesignJet printers; rely on a single support solution.
Avoid reprints – large touchscreen to preview, enhance images; post-scan editing with HP SmartStream software.[2]
Protect your data with advanced security – set up a password to scan to USB and access advanced settings.
Build a multifunction system[4] – save space with the adjustable stand and easily control output destinations.[5]
Description
Specifications
Scanning | |
---|---|
Maximum scan size | 1067 x 75760 mm |
Optical scanning resolution | 1200 x 1200 DPI |
Enhanced scan resolution | 9600 x 9600 DPI |
Colour scanning | Yes |
Duplex scanning | No |
Input colour depth | 48 bit |
Film scanning | Yes |
Design | |
Built-in display | Yes |
Product colour | Black |
Display diagonal | 39.6 cm (15.6") |
Touchscreen | Yes |
Scanner type | Sheet-fed scanner |
Performance | |
Sensor type | CCD |
Scan file formats | JPEG, PDF, TIFF |
Daily duty cycle (max) | 0 pages |
Scan to | E-mail, FTP, File, USB |
Internal memory | 4096 MB |
Paper handling | |
Maximum ISO A-series paper size | A0 |
Ports & interfaces | |
USB port | Yes |
USB version | 3.2 Gen 1 (3.1 Gen 1) |
Network | |
Ethernet LAN | Yes |
Power | |
Power supply type | AC |
Power consumption (typical) | 130 W |
Power consumption (standby) | 39 W |
Input voltage | 100-240 V |
AC input frequency | 50 - 60 Hz |
Weight & dimensions | |
Width | 1530 mm |
Depth | 930 mm |
Height | 1660 mm |
Weight | 71 kg |
Package width | 1910 mm |
Package depth | 680 mm |
Package height | 800 mm |
Package weight | 118 kg |
Packaging data | |
Package width | 1910 mm |
Package depth | 680 mm |
Package height | 800 mm |
Package weight | 118 kg |
Sustainability | |
Sustainability certificates | ENERGY STAR |
Operational conditions | |
Operating temperature (T-T) | 5 - 35 °C |
Storage temperature (T-T) | -25 - 55 °C |
Operating relative humidity (H-H) | 20 - 80% |
Storage relative humidity (H-H) | 0 - 95% |
Other features | |
Compliance certificates | RoHS |
Ethernet LAN | Yes |
Scanner type | Sheet-fed scanner |
Technical details | |
Sustainability certificates | ENERGY STAR |
Compliance certificates | RoHS |
