CyberPower OL10KERTHD uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 10000 W 10 AC outlet(s)
- Brand: CyberPower
- Category:
- SKU: OL10KERTHD
- EAN: 4711027799025
10000VA,10000 Watts.Output Voltage ( Vac ) 200 ± 2% / 208 ± 2% / 220 ± 2% / 230 ± 2% / 240 ± 2%, Half Load Runtime ( min ) 8.3
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
Online Series 10000VA/10000W Rack/Tower Online UPS - 4U - Built-in Equalisation Module (EQM) for battery life extension(OL10KERTHD) -2 Yr WTY |
CP89091 | |||
|
CP OL10000VA Rack Tower UPS |
CPOL10KERTHD | |||
|
Online Series 10000VA/10000W Rack/Tower Online UPS - 4U - 12 12V/AH - 4x IEC C19 6x IEC C13 1x Hardwire Terminal Block - USB Combo Built-in SNMP Equalisation Module for battery life extension support |
5818019 |
Retail Prices
| Merchant | Product | Condition | Updated | Price |
|---|---|---|---|---|
| Amazon | New | $10,475.99 |
Description
CyberPower OL10KERTHD guarantees power backup protection for IT equipment, servers, workstations, NAS/Storage devices, telecom devices, networking devices, security/emergency systems, and surveillance systems. The UPS adopts double-conversion topology to provide high-quality power output in a compact design. This generator-compatible UPS features hot-swappable battery packs for maintenance without power interruption, and comes with additional ECO Mode to conserve power and save on energy costs.
The UPS can employ Extended Battery Modules (EBM) to prolong runtimes, and adopts patented Battery Management Technology to balance battery string voltage for optimal battery lifespan. This model also features tiltable color LCD panel that allows users to monitor key power and battery information at a glance. The PowerPanel Power Management Software allows user to perform real-time monitoring and remote management of the UPS.
The UPS can employ Extended Battery Modules (EBM) to prolong runtimes, and adopts patented Battery Management Technology to balance battery string voltage for optimal battery lifespan. This model also features tiltable color LCD panel that allows users to monitor key power and battery information at a glance. The PowerPanel Power Management Software allows user to perform real-time monitoring and remote management of the UPS.
Specifications
| Power | |
|---|---|
| Output frequency | 50/60 Hz |
| Output power capacity | 10 kVA |
| Output power | 10000 W |
| Input operation voltage (min) | 200 V |
| Input operation voltage (max) | 240 V |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 2430 J |
| Maximum current | 55 A |
| Emergency Power Off (EPO) | Yes |
| Power factor | 1 |
| Crest factor | 3:1 |
| Total Harmonic Distortion (THD) (linear load) | 3% |
| Total Harmonic Distortion (THD) (non-linear load) | 5% |
| ECO mode | Yes |
| Input frequency | 50/60 Hz |
| Battery | |
| Battery type | RBP0159 |
| Battery technology | Lead-Calcium (Pb-Ca) |
| Battery recharge time | 4 h |
| Typical backup time at half load | 8.3 min |
| Typical backup time at full load | 2.4 min |
| Hot-swap battery | Yes |
| Battery voltage | 192 V |
| Performance | |
| UPS topology | Double-conversion (Online) |
| EMI/RFI noise filtering | Yes |
| Surge protection | Yes |
| Waveform | Pure sine |
| Audible alarm(s) | Yes |
| Features | |
| Output frequency | 50/60 Hz |
| Country of origin | China |
| UPS topology | Double-conversion (Online) |
| Output power capacity | 10 kVA |
| Output power | 10000 W |
| Input operation voltage (min) | 200 V |
| Input operation voltage (max) | 240 V |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 2430 J |
| Maximum current | 55 A |
| EMI/RFI noise filtering | Yes |
| Surge protection | Yes |
| Emergency Power Off (EPO) | Yes |
| Waveform | Pure sine |
| Power factor | 1 |
| Crest factor | 3:1 |
| Audible alarm(s) | Yes |
| Total Harmonic Distortion (THD) (linear load) | 3% |
| Total Harmonic Distortion (THD) (non-linear load) | 5% |
| ECO mode | Yes |
| Input frequency | 50/60 Hz |
| Heat dissipation | 2044 BTU/h |
| Ports & interfaces | |
| USB port | Yes |
| Serial interface | Yes |
| AC outlets quantity | 10 AC outlet(s) |
| AC outlet types | C13 coupler, C19 coupler, Terminal |
| Power plug | Terminal |
| USB 2.0 ports quantity | 1 |
| Serial ports quantity | 1 |
| Design | |
| Country of origin | China |
| Rack capacity | 4U |
| Form factor | Rackmount/Tower |
| Product colour | Black |
| Built-in fan | Yes |
| Housing material | Metal |
| Control type | Buttons |
| Display type | LCD |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -5 - 45 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 4500 m |
| Technical details | |
| Output frequency | 50/60 Hz |
| Sustainability compliance | Yes |
| Harmonized System (HS) code | 8504408690 |
| Compliance certificates | CE, EAC, RCM, RoHS |
| Cooling | |
| Built-in fan | Yes |
| Weight & dimensions | |
| Width | 433 mm |
| Depth | 720 mm |
| Height | 173 mm |
| Weight | 71.2 kg |
| Package width | 590 mm |
| Package depth | 890 mm |
| Package height | 488 mm |
| Package weight | 92 kg |
| Packaging data | |
| Package width | 590 mm |
| Package depth | 890 mm |
| Package height | 488 mm |
| Package weight | 92 kg |
| Logistics data | |
| Harmonized System (HS) code | 8504408690 |
| Other features | |
| Battery type | RBP0159 |
